LUX 1.3
LX1.3 1080P PNG.pngLUX 1.3
Architectural Linear Luminaire
This luminaire features a 1.3” aluminum profile in White or Black, available in 2, 4, and 8-foot lengths. It offers soft, even direct/indirect illumination with a frosted polycarbonate lens and field-selectable CCT options. cULus listed for damp locations, with a dimmable power supply and long-lasting LED performance.
Resources
CCT
- Field Selectable CCT
- 3000K
- 3500K
- 4000K
CRI
- 80 CRI
Color / Finish
- Black
- White
Dimensions
- H: 2.24 In. L: 25.28 In. W: 1.30 In.
Dimming Protocol
- 0-10 V
Distribution
- Direct/Indirect
Lamp Life
- 50000 hrs
Mounting
- Surface
- Suspended
- Wall
Ratings & Compliance
- Assembled in America
- Damp
Shape
- Linear
Voltage
- 120-277 V
Watts
- 10 w
- 15 w
- 20 w
- 30 w
- 40 w
- 60 w
- 80 w
