New Product
Architectural T-Grid Gen 2 Luminaire
The GF-G2 is a luminaire that transforms grid ceilings with a modern design, available in 1x4, 2x2, and 2x4 sizes. It features field-selectable lumen output and CCT, with a remote driver and 0-10V dimming. Field-selectable CCT from 2700K ~ 5000K and field selectable wattage from 20W~50W; 120° distribution; >90 CRI; >100,000 hours lifespan; cULus damp location listed.
Resources
Beam Angle
- 120
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 90 CRI
Color / Finish
- White
Dimensions
- L: 4 In. W: 1 In.
- L: 4 In. W: 2 In.
- L: 2 In. W: 2 In.
Dimming Protocol
- 0-10 V
Dimming Range
- 10%
Emergency Options
- Emergency Battery Backup
Lamp Life
- 100001 hrs
Listings
- cULus
Lumens
- 2500 Lm
- 3800 Lm
- 5500 Lm
- 6500 Lm
Materials
- Aluminum
Mounting
- Grid
- T-Grid
Ratings & Compliance
- Buy American Act (BAA)
- Damp
Shape
- Rectangular
- Square
Special Programs
- Quick Ship
Voltage
- 120-277 V
Watts
- w
- 20 w
- 30 w
- 40 w
- 50 w
